Basic Unit
Vessel: Total volume: 50L, load coefficient is 70%. Stainless steel (316L) vessel with wide sight glass. The design pressure: P(inside)= 0.3Mpa, P(inter layer)=0.3Mpa, The polishing precision: Ra0.4 to 0.6,the ratio between diameter and height: 1:2.56.
Stirrer: Drive with AC motor, speed adjustable. Direct-coupled mechanical drive from top, with mechanical sealing Solid stirrer shaft with 2 pieces of 6-blade disk impeller and 1 set of foam breaker. Rotate speed range: 100-1000rpm.
Aeration: Manual control ventilatory capacity, the precision of inhaler : 0.02μm, displayed by rotameter.
Thermal circuit: Heat by thermostatic water tank and circulate by circulating pump(Grundfos, Denmark),auto control (cooling water+5℃)~50℃±0.2℃.
PH: 2.00-12.00±0.05pH, auto control by adding acid and alkali.
DO of Fermentation Unit: 0-150±3%displaying precision 0.1%.
Feeding: with peristaltic pump.
Anti-foam: Auto-detected and adding anti-foam by peristaltic pump.
Pressure: Manual control exhaust by diaphragm valve, and displayed by pressure gauge.
Sterilization: In situ with external steam.
Control system: Various controller for choose. Details: BIOTECH-7000, BIOTECH-9000

Optional for Stainless Steel Fermenter
1. Auto detect and auto control of air mass flow, pressure, liquid level
2. Detect of exhaust O2 and CO2
3. Additional pump for feed
4. Weight system for vessel and feeding
5. Auto- Sterilization
6. Other customized functions
